Solar Water Heater From Haining

We closely follow the development of domestic and foreign technology and seize the high point of 10 tubes solar water heater, vacuum tube collector, solar panel water heater industry technology. The purpose of our talent management is to condense talents with grand cause and encourage talents with scientific mechanism. Our company has its own core technology, built its own brand, and also has transnational business talents. We are committed to creating a fair, objective and open promotion platform. Our company adopts modern production operation mode and strictly implements and executes quality standards in all aspects of production and management.

DESCRIPTION

Flat plate solar collector is a device that absorbs solar radiation energy and transfers heat to the working medium. It is a special heat exchanger. The working medium in the collector exchanges heat with the distant sun. Flat plate solar collector is composed of a heat-absorbing plate core, a shell, a transparent cover plate, thermal insulation materials and related parts and components. After the circulation pipeline and the heat preservation water tank are added, it becomes able to absorb solar radiation heat and raise the water temperature.

FEATURES

The basic working principle of the flat panel solar collector is very simple. In a nutshell, sunlight shines through the transparent cover plate onto the heat absorbing body coated with an absorption layer, and most of the solar radiation energy is absorbed by the absorbing body, converted into heat energy, and transferred to the working fluid in the fluid channel. In this way, the cold working fluid from the inlet of the bottom of the collector is heated by solar energy in the fluid channel, and the temperature gradually rises. The heated thermal working medium carries useful heat energy from the upper outlet of the collector and stores it into the storage water. Standby in the box is the useful energy gain. At the same time, as the temperature of the heat absorbing body rises, heat is dissipated to the environment through the transparent cover plate and the outer shell, which constitutes various heat losses of the flat solar collector.

SPECIFICATION

Steel punching	Argon arc welding
Leakage inspection	Flat panel

Storage

Flat plate solar collector absorbs solar radiation then transfers heat to flow medium.It is composed of a heat-absorbing plate core, a shell, a transparent cover plate, thermal insulation materials and related parts and components. After the circulation pipeline and the heat preservation water tank are added, it becomes able to absorb solar radiation heat and raise the water temperature.

Le capteur solaire à plaque plate absorbe le rayonnement solaire puis transfère la chaleur au fluide d'écoulement. Il est composé d'un noyau de plaque absorbant la chaleur, d'une coque, d'une plaque de couverture transparente, de matériaux d'isolation thermique et de pièces et composants connexes. Une fois la canalisation de circulation et le réservoir d'eau de conservation de la chaleur ajoutés, il devient capable d'absorber la chaleur du rayonnement solaire et d'augmenter la température de l'eau.

Flat-plate collectors have been widely used in many fields such as domestic water heating, swimming pool heating, industrial water heating, building heating and air conditioning. A water heater composed of flat panel solar collector components is a flat panel solar water heater. Flat-plate solar collectors are mainly composed of flat-plate solar collector heat-absorbing plates, flat-plate solar collectors transparent cover plates, flat-plate solar collectors heat insulation layer and flat-plate solar collector shells.

Flat plate solar collectors are the basic components for solar low-temperature heat utilization, and they have always been the leading products in the world's solar energy market.

Predominance: The pressure testing 9kgf/cm2 ; Ultrasonic strip welding technology; Not change the character of materials; The coefficient of heat conductivity is unchanged;

Flat Plate Solar Collector Component

1. Frame: Alunimum Alloy,

2. Board Inner Core: Purple Copper

3. Layer: Plating Black Chrome (Absorptance 95%, Emittance 10%)

4. Cover Board: 4mm Toughened Glass

5. Heat Conservation: Rock Cotton (Back), Polythene (Side);

6. Back Board: 0.5mm Galvanized Board

1- Ordinary TXT coating: Absorptance 93%, Emittance 45%~50%;

2- Plating Chrome plating coating: Absorptance 95%~96%, Emittance 10%;

3- TINOX (Germany) coating: Absorptance 96%, Emittance 6%.

We believe that by constantly improving the specifications and levels of our products, we can also ensure the stability of our Solar Water Heater From Haining. The company has always followed the principles of integrity, quality and service, and insisted on providing customers with high-quality products, services and good after-sales service. Doing business with mutual benefit and making friends sincerely are our company's criteria, which are well received by the majority of new and old customers.
